15.6" Full HD Industrial Tablet. The LPC-KR156-W features a high-resolution 1920x1080 display, making it ideal for visual inspection and complex HMI tasks. Powered by customizable Intel® processors (6th-13th Gen) and housed in a durable fanless aluminum chassis, it supports 9-36V wide voltage input and offers reliable performance in industrial environments.
The LPC-KR156-W is a widescreen 15.6-inch industrial panel PC with a stunning 1920x1080 Full HD display. It offers a larger visual workspace for complex HMI interfaces and monitoring dashboards. Built with a rugged aluminum alloy enclosure and supporting customizable Intel® processors (6th to 13th Gen), it is engineered for stability and longevity in harsh industrial settings.
| Parameter | Specification |
|---|---|
| Processor | Intel® Core™ / Celeron® (Customizable 6th-13th Gen) |
| Memory | Customizable (4GB - 16GB Optional) |
| Display | 15.6" TFT LCD (1920 x 1080 FHD Resolution) |
| Touch Screen | Capacitive Touch (10-point) / Resistive Optional |
| Storage | 1x M.2 SSD, 1x 2.5" HDD/SSD (Customizable) |
| Network | 2x Gigabit Ethernet (RJ45) |
| I/O Interface | 2x USB 3.0, 2x COM (Optional 6x COM), 1x HDMI |
| Expansion | 1x MiniPCIe (WiFi/BT), GPIO Optional |
| Power Input | DC 12V / 9V-36V (5A) |
| Dimensions | Refer to Size Chart (Approx 56.5mm thickness) |
| OS Support | Windows 10/11, Linux |
Equipped with a 15.6-inch 1920x1080 Full HD display, delivering crisp visuals for data-rich applications.
Compatible with a wide range of Intel® Core™ and Celeron® processors (6th to 13th Gen) to meet specific performance needs.
Fully enclosed die-cast aluminum alloy body (~56.5mm thick) provides excellent heat dissipation, dust protection, and vibration resistance.
Equipped with 2x COM (Optional 6x), 2x Gigabit LAN, and 2x USB 3.0 ports for seamless device integration.
Supports DC 12V input with an option for 9-36V wide voltage, ensuring stability in fluctuating power conditions.
面向工业自动化与控制系统的高可靠解决方案。
以高性能计算能力支撑 AI 质检与识别场景。
在网络边缘实现低延迟数据聚合与实时分析。
PDF | 0.01 MB
该产品适用于智能制造、机器视觉、边缘数据采集与网关控制等场景。根据当前规格，可在 -20°C ~ 60°C 条件下承载 7x24 小时持续运行任务，并支持 Windows 10, Windows 11, Linux 软件环境。
产品分类：工业一体机；处理器：Intel® Core™ / Celeron® (Customizable 6th-13th Gen)；内存：Customizable (4GB - 16GB Optional)；网络：N/A；环境温度：-20°C ~ 60°C。以上参数可用于项目初筛与兼容性评估。
当前产品提供 1 项可下载资料（如驱动、手册或相关文件），可用于缩短评估与集成周期。
LPC-KR156-W 15.6" FHD Industrial Panel PC 主要用于 工业一体机 相关项目，适合对稳定性和持续运行能力要求较高的工业场景。
通常可支持 Windows 10, Windows 11, Linux。具体以项目镜像、驱动与外设适配要求为准。
支持。可按项目需求提供接口扩展、外观标识与方案级定制。
